No Crimp
Material
b> ASTM-A653 CS Type B Galvanized Steel, G-30 Coating LFQ Chemical Treatment
Gauge
26GA
Assembly
Machine cut body assembled with C-115 2/16 zinc coated steel rivets. Collars are beaded onto reducer. Body may be die stamped and assembled with 2/16″ rivets.
Collar
2″ Roll formed Galvanized Steel features 1/8″ hemmed edge
Option
Available crimped on small end: 265C
| SKU | Description | Box Qty. |
|---|---|---|
| 265106 | 265 10 X 6 REDUCER | 12 |
| 265108 | 265 10 X 8 REDUCER | 24 |
| 265109 | 265 10 X 9 REDUCER | 24 |
| 2651210 | 265 12 X 10 REDUCER | 12 |
| 265128 | 265 12 X 8 REDUCER | 12 |
| 2651410 | 265 14 X 10 REDUCER | 12 |
| 2651412 | 265 14 X 12 REDUCER | 12 |
| 2651612 | 265 16 X 12 REDUCER | 12 |
| 2651614 | 265 16 X 14 REDUCER | 12 |
| 2651816 | 265 18 X 16 REDUCER | 12 |
| 2652018 | 265 20 X 18 REDUCER | 5 |
| 26543 | 265 4 X 3 REDUCER | 24 |
| 26553 | 265 5 X 3 REDUCER | 24 |
| 26554 | 265 5 X 4 REDUCER | 24 |
| 26564 | 265 6 X 4 REDUCER | 24 |
| 26565 | 265 6 X 5 REDUCER | 24 |
| 26576 | 265 7 X 6 REDUCER | 24 |
| 26586 | 265 8 X 6 REDUCER | 24 |
| 26587 | 265 8 X 7 REDUCER | 24 |
| 26598 | 265 9 X 8 REDUCER | 12 |
